PVS-14 Autogated Night Vision Monocular (Coyote Tan)


From N-Vision Optics | Model #: NVNCP14AG3CT



See more in


PVS-14 Autogated Night Vision Monocular (Coyote Tan)

Product Description

The coyote tan PVS-14 Autogated Night Vision Monocular from N-Vision is a Gen III image intensification device designed for tactical professionals and first responders. At the core of the PVS-14 is a third generation image intensifier tube that delivers 57-72 lp/mm resolution with automatic brightness control and cut-off circuitry that automatically interrupts power to the tube in the presence of bright light sources. This tube also has an autogated power supply that constantly operates to minimize blooming caused by bright points of light in the visual scene.

The PVS-14 features 1.0x magnification, providing a 40 degree angle of view that aids situational awareness and allows the operator to effectively use a both eyes open technique in low-light conditions. The standard viewing angle combined with bright f/1.12 optics makes this monocular suited for aviation, close-quarter engagement, surveillance and recon. This NVD is head, helmet, weapon, camera, and tripod-mountable; when used with the wide range of compatible accessories, the PVS-14 can handle almost any low-light/no-light mission.

Intensifier Tube Gen III autogated
Resolution 57 - 72 lp/mm
Magnification 1.0x
Angle/Field of View 40°
Lens System 26 mm, f/1.2
Eye Relief 25 mm
Minimum Focus Distance 10" (26 cm)
Dioptric Correction -6 to 2
Infrared Illuminator Yes
Power Supply (1) AA battery
Runtime Up to 40 hours of continuous operation at room temperature
Weatherproofing Submersible to 66 ft (20 m)
Operating Temperature -60 to 120°F (-51 to 49°C)
Storage Temperature -60 to 185°F (-51 to 85°C)
Dimensions 4.5 x 2.4 x 2" (11 x 6 x 5 cm)
Weight 13.5 oz (380 g)
