Product Description
The HF G20 has 32GB of built-in memory that supports up to 12 hours of HD video. It also features two SD/SDHC/SDXC memory card slots that you can use for Relay Recording, which automatically switches video recording to the memory card when the internal drive becomes full. The camera features Dynamic SuperRange Optical Image Stabilization as well. Other features of the HF G20 include a 3.5" touch panel LCD, a 0.24" color viewfinder, a 58mm filter diameter and Smart AUTO function.
The HF G20 has a number of professional shooting functions as well. These include custom key and dial, composition aids and advanced control like manual exposure, aperture priority and shutter priority. It also supports Audio Scene Select and a highly adjustable internal microphone. For more professional audio, the HF G20 has headphone and microphone jacks. It has HDMI and USB connectivity as well. Plus, the Mini Advanced Accessory Shoe supports attachment of a variety of shooting aids including lights and microphones.
| Camera | |
| Sensor | 1/3" CMOS |
| Color Filter | RGB |
| Sensor Resolution | 2,370,000 MP |
| Effective Pixels | 2,070,000 MP |
| Optics | |
| Focal Length | 4.25 - 42.5mm |
| 35mm-Equivalent Focal Length | 30.4 - 304 |
| Maximum Aperture | f/1.8 - f/2.8 |
| Minimum Focusing Distance | 0.8" / 2.0 cm |
| Zoom | Optical: 10x Digital: 40x Digital: 200x |
| Filter Size | 58 mm |
| Sensor | |
| Pixel Gross | |
| Focal Length | |
| 35mm-Equivalent Focal Length | |
| Maximum Aperture | |
| Minimum Focusing Distance | |
| Fixed Focus | |
| Angle of View | |
| Recording | |
| System | NTSC |
| Recording Media | Internal Flash Memory (32 GB Maximum) SD/SDHC/SDXC SD/SDHC/SDXC |
| Recording Time | Internal Flash Memory 32 GB AVCHD LP (1440 x 1080, 5 Mbps): 12.3 hours AVCHD SP (1440 x 1080, 7 Mbps): 9.6 hours AVCHD XP+ (1440 x 1080, 12 Mbps): 5.8 hours AVCHD FXP (1920 x 1080, 17 Mbps): 4.2 hours AVCHD MXP (1920 x 1080, 24 Mbps): 2.9 hours |
| Video Format | 1920 x 1080i at 60 fps (AVCHD) 1920 x 1080p at 24, 30 fps (AVCHD) 1440 x 1080p (AVCHD) |
| Still Image Resolution | JPEG: 2.07 Megapixel, 1920 x 1080 |
| Channels | 2.0-ChannelStereo |
| Audio Format | Dolby Digital AC3 |
| Display | |
| Display Type | LCD |
| Touchscreen | Yes |
| Screen Size | 3.5" |
| Exposure Control | |
| Shutter Speed | 1/2000 Second () |
| Photo ISO Range | |
| Video ISO Range | |
| Streaming ISO Range | |
| Features | |
| Image Stabilization | Optical & Digital |
| IP Rating | |
| Lux | 1.2 (NTSC Auto Mode with auto slow 1/30 sec shutter speed selected) .1 (Low Light Mode with 1/2 sec shutter speed) |
| Built-In Mic | Yes |
| Built-In Speaker | Yes |
| Built-In Light/Flash | Light - No Flash - No |
| Accessory Shoe | Mini Hot |
| Tripod Mount | 1/4" |
| Input/Output Connectors | |
| Inputs | 1 x LANC Terminal for Remote |
| Outputs | 1 x Mini-HDMI (Type C) (output only) 1 x USB Mini-B (Hi-Speed USB supported) 1 x Composite Video 1 x Component Video 1 x A/V Mini Terminal / Headphone Terminal (4 pole mini-jack) |
| Microphone Input | Yes |
| Headphone Jack | Yes |
| General | |
| Battery | Rechargeable Lithium-Ion Battery Pack |
| Charging Method | AC Adapter |
| Power Adapter | Not Specified by Manufacturer |
| Operating Temperature | 23 to 113°F / -5 to 45°C Humidity: 60% 32 to 104°F / 0 to 40°C Humidity: 85% |
| Dimensions (W x H x D) | 3.0 x 3.1 x 6.3" / 7.6 x 7.9 x 16.0 cm not including lens hood and grip belt |
| Weight | 1.27 lb / 576.06 g including lens hood and grip belt 1.36 lb / 616.88 g including battery BP-808, one memory card, lens hood and grip belt |
